Christie D13WU2-HS Laser Projector
Christie D13WU2-HS 13,500 lumen, WUXGA, 1DLP laser projector 171-014106-XX
Enjoy the performance of advanced electronics. With 13,500 lumens, the Christie® D13WU2-HS is equipped with advanced 1DLP® laser projection technology to operate at full-brightness on a single 15A, 110V circuit. There’s no need for high-power runs. Simply plug into a standard outlet and start the show!
Visuals are stunning thanks to the enhanced color accuracy of Christie’s BoldColor™ Technology and WUXGA resolution. The long-lasting and reliable laser light source and affordability of 1DLP technology means the D13WU2-HS is a cost-effective option for high-use applications. Featuring the built-in Christie Twist™ warping and blending engine, and compatible with Christie Mystique® automated camera-based alignment solutions, the D13WU2-HS gives you the tools you need to quickly and easily set up, align, and maintain irregular screens and multi-projector displays.
Key features
- Christie BoldColor Technology – Enhanced color performance and saturation over standard laser projection
- Long-life laser light source – Up to 20,000 hours to 50% brightness of virtually maintenance-free operation
- Warp and blend – Built-in Christie Twist for quick and easy setup of multi-projector displays
- Compatible with Christie Mystique – Automated camera-based alignment solutions that eliminate the challenges, time and expertise required to align, stack, warp and blend complex multi-projector arrays and projection mapping experiences
- Fully omnidirectional – Unrestricted design and installation flexibility
- Lens compatibility – Designed to work with all Christie HS Series lenses for added cost-savings and versatility
- Comprehensive connectivity – Full connectivity for popular formats including 3GSDI for added redundancies
- Christie Virtual Remote 1DL – Gives you wireless control from any smartphone or tablet
- Advanced electronics – Firmware updates take only minutes
- TAA Compliant
Additional information
| ISO lumens | 13,500 |
|---|---|
| ANSI lumens | 12,500 |
| Contrast ratio | Full On/Off (Christie Real Black enabled): 2,000,000:1 , Full On/Off (Christie Real Black disabled): 1,200:1 |
| Dynamic contrast | 6,000:1 |
| Display type | 1 x 0.96" DMD |
| Resolution | WUXGA (1920 x 1200) |
| Illumination type | Laser phosphor with Christie BoldColor Technology |
| Illumination performance (hrs) | 20,000 to 50% brightness |
| Scan rates | Horizontal: 15-91kHz Vertical: 24-85Hz |
| Pixel clock rate | 162 MHz |
| Signal Input | Standard: - HDMI x 2 (one on rear panel, one on bottom of projector, independently selectable) - 3GSDI (BNC) - DVI-D (digital only) - USB (type A) - image viewer or WiFi dongle (optional) - HDBaseT (RJ45) Signals: - HDTV formats VGA through to WUXGA (1920 x 1200) 3D Inputs - HDMI 1.4, HDBaseT - frame packed, top/bottom, side-byside (up to 120Hz output) - 3D Sync In (BNC) - for genlocking projectors - 3D Sync Out (BNC) - for genlocking projectors or controlling emitters |
| Signal output | - 3GSDI (BNC) - HDMI x1 (HDMI out) |
| Control & networking | - RS232 In - Control via HDBaseT - Ethernet (10/100) RJ45 - Built-in backlit keypad - Wired remote control (3.5mm stereo) - loop out available for daisy chaining - 12VDC trigger at 200mA (ID:2.5mm) |
| Warpin​g and blending | Standard: - Christie Twist Optional: - Christie Twist Premium and Twist Pro - Christie Mystique automated camera-based alignment |
| Lens mount | - Boresight adjustable - Motorized horizontal and vertical lens offset (memory available) - Motorized zoom and focus adjustment (memory available for full ILS lenses) |
| Lens options | Lenses: - 0.38:1 UST lens - 0.84-1.02:1 - 1.02-1.36:1 - 1.2-1.5:1 - 1.5-2.0:1 - 2.0-4.0:1 - 4.0-7.0:1 |
| Power requirements | Operating voltage: - Normal: 120-240VAC @ 60/50 Hz with 15A fuse Power consumption: - Normal mode: 1710W - Eco1 mode: 1380W - Eco2 mode: 830W Operating current: - Normal mode: 9A (200-240 VAC) |
| Dissipation | - Normal mode: 5835 BTU/hr - Eco1 mode: 4709 BTU/hr - Eco2 mode: 2832 BTU/hr |
| Audible noise | - Typical: 44dBA - Eco mode: 36dBA |
| Dimensions (LxWxH) | 26.65 x 23.46 x 7.99" without feet 677 x 596 x 203mm without feet Shipping dimensions: 36.34 x 33.19 x 20.20" 923 x 843 x 513mm |
| Weight | 91.52lbs (41.6kg) |
| Operating environment | - Temp: 0 to 40° C (32 to 104° F) - Humidity: 10 - 85% non-condensing |
| Regulatory | - Contact Christie for the timing of certifications: - UL/CSA/IEC 60950-1 FCC Class A CE FDA CCC KC PSE CU BIS VCCI RCM TER - This product conforms to all relevant European directives, standards, safety, health and environmental concerns - RoHS REACH WEEE |
| Limited Warranty | - Three years parts and labor on the projector - Three years or 20,000 hours parts and labor on the illumination system* - Contact an authorized Christie representative for full details of our limited warranty - *Please reference the Christie Standard Limited Warranty document for details. |
| Accessories (standard) | Standard: - IR remote w/ wired remote jack (wire not included) - AC line cords for projector head - User manual Optional: - 1DWUSB-BGN (wireless dongle for video and control) - HS fog filter covers + filters (order once per projector then only filters refills) - HS fog filter refills (1 set) - Replacement remote control |
