Nationwide Video is excited to offer this new Disguise VX4+ and GX3 Promotion! When you purchase a new Disguise VX4+, receive the second one half off. When you purchase a new Disguise GX3, receive the second one half off.
Disguise VX4+
The Disguise VX4+ is a professional-grade media server engineered to power the most demanding live events, virtual productions, and large-scale visual experiences with reliable, high-performance video playback. It features advanced hardware — including a PCIe 4.0 motherboard, high-end CPU, GPU, and RAID NVMe storage — that delivers significantly improved throughput and the ability to handle more than twice the video layers of its predecessor. With dual 100 GbE networking and robust video I/O options, the VX4+ supports seamless 4K extended reality (xR) compositing and real-time graphics workflows. Designed as part of the modular Disguise ecosystem, it integrates easily with RenderStream, VFC cards, and render node clusters for scalable content creation. The ruggedized 4U rack-mount chassis includes a hi-res OLED front panel for system monitoring and LED indicators for quick server identification. Whether used for live concerts, broadcast, or immersive environments, the VX4+ offers future-proof performance and the bandwidth needed to keep complex visuals running smoothly and without dropped frames.
Disguise GX3
The Disguise GX 3 is a high-performance media server engineered to drive complex visual experiences across live events, XR productions, and immersive installations with robust real-time playback power. It combines a workstation-class NVIDIA A6000 GPU and 96 GB of RAM to deliver over 53,000 Notchmarks, unlocking advanced generative graphics capabilities and supporting intricate real-time effects like facial tracking and simulation. Designed in a ruggedised 4U rack-mount chassis with a hi-res OLED front panel and dual 100 GbE network ports, it meets the demands of touring shows and large-scale productions alike. The system includes high-bandwidth storage with a 3.84 TB removable NVMe drive, enabling creative teams to work comfortably with high-quality codecs and large video files. With flexible video I/O — including multiple 12G inputs and VFC output slots — the GX 3 adapts to diverse workflow requirements and integrates seamlessly into existing AV infrastructures. Whether powering concert tours, festivals, or broadcast stages, the GX 3 delivers reliable performance and real-time playback versatility for demanding visual productions.
Additional information
| Inputs | Up to 48x 4K concurrent inputs through 6 input cards Standard, custom and advanced EDID settings Custom resolutions: 3840x2160@60Hz, 4096x2160@60Hz, 8192x1080@60Hz, etc Input source deinterlacing processing on 4 connectors of each input card Input source cropping Status LED indicators provided for easy troubleshooting |
|---|---|
| Outputs | Up to 16x 4K concurrent outputs through 4 output cards Standard, custom and advanced output timing settings Output width up to 8192 pixels, better choice for LED applications Status LED indicators provided for easy troubleshooting |
| Multiviewer | Two dedicated output connectors configured as Multiviewer connectors, with resolutions adjustable Independent and copying modes: The two connectors display different Multiviewer images, or the HDMI 2 copies the HDMI 1 output Monitor all inputs and screens (PVW and PGM) Customizable layouts for easy use UMD display and color adjustment Border adjustment for Multiviewer windows |
| Screens | Output configured as single screens or edge-blended widescreens Bezel compensation and edge blending Irregular screen mosaic and output AOI function, ideal for complex and irregular LED screen applications The sync source can be set independently for each screen |
| Transition & Effects | Luma key and chroma key Cut and fade transitions Customizable transition durations PVW to PGM via Take, Cut or T-bar operation Copy or Swap mode for PVW to PGM transition |
| Layers | Each Q8 supports up to 32x 4K mixing layers in switcher mode or 64x 4K single layers in PGM only mode Full screen roaming supported Fade and Cut effects for PVW to PGM transition Adjustable layer mask and border with different border effects Layer flipping, copying and mirroring |
| Still Image Management | Still images can be imported or captured from input or output Unlimited still image quantity in 1G storage space Still images can be used as BKG and still layers Independent BKG for each screen BKG filling the whole screen by default |
| Processing | FPGA based high performance image processing architecture with SuperView scaling engine inside Ultra-low latency, as low as 1 frame in proper configuration BT.601, BT.709, BT.2020, DCI-P3 color space processing support Advanced keying capability: chroma key and luma key Compatible with HDCP 1.3, HDCP 1.4 and HDCP 2.2 |
| Control Options | Event controller U5/U5 Pro Event management software PixelFlow |
| PixelFlow Functionalities | Long-term stable running Upgraded and visualized UI, adaptive to U5/U5 Pro/PC screens One click to change skins of U5/U5 Pro buttons Software parameter controllable by U5/U5 Pro encoders or faders Distinct function areas and hover menu for ease of use |
| Input Card | 8x 4Kx2K concurrent inputs per input card 4x HDMI 2.0 Up to 4Kx2K@60Hz 10bit 4:2:2, or 4Kx2K@60Hz 8bit 4:4:4 Support for processing of 8-bit, 10-bit and 12-bit inputs Support for 4:2:0, 4:2:2 and 4:4:4 inputs Support for processing of Full and Limited range videos Support for HDR video inputs HDCP 1.4 and HDCP 2.2 compliant Support for deinterlacing processing Custom resolutions Maximum width: 8192 pixels Maximum height: 8192 pixels 4x DP 1.2 Up to 4Kx2K@60Hz 10bit 4:4:4, or 4Kx2K@60Hz 8bit 4:4:4 Support for processing of 8-bit, 10-bit and 12-bit inputs Support for 4:2:2 and 4:4:4 inputs Support for processing of Full and Limited range videos Support for HDR video inputs HDCP 1.3 and HDCP 2.2 compliant Custom resolutions Maximum width: 8192 pixels Maximum height: 8192 pixels 4x 12G-SDI Support for ST-2082 (12G), ST-2081 (6G), ST-424 (3G), ST-292 (HD) and ST-259 (SD) standard video inputs Compatible with SD-SDI, HD-SDI, 3G-SDI and 6G-SDI Support for interlaced signal inputs No support for EDID management or bit depth settings |
| Output Card | 4x HDMI 2.0 and 4x 12G-SDI connectors are divided into 4 groups. Each group includes 1x HDMI 2.0 and 1x 12G-SDI connectors. In each group, only 1 connector can be used for output each time. Connector 1 (HDMI 2.0) and connector 5 (12G-SDI) are in a group. Connector 2 (HDMI 2.0) and connector 6 (12G-SDI) are in a group. Connector 3 (HDMI 2.0) and connector 7 (12G-SDI) are in a group. Connector 4 (HDMI 2.0) and connector 8 (12G-SDI) are in a group. 4x HDMI 2.0 Up to 4Kx2K@60Hz 8bit 4:4:4 output Support for 8-bit and 10-bit output settings Support for 4:2:2 and 4:4:4 output settings Support for YCbCr and RGB color space settings No support for interlaced signal outputs Custom resolutions Maximum width: 8192 pixels Maximum height: 8192 pixels 4x 12G-SDI Compatible with SD-SDI, HD-SDI, 3G-SDI and 6G-SDI Support for interlaced signal outputs 8x 10G OPT Support for single-mode and multi-mode optical outputs Transmission distance up to 10km in single mode OPT ports copy outputs on video connectors OPT 1 and OPT 2 copy the output on connector 1 or 5. OPT 3 and OPT 4 copy the output on connector 2 or 6. OPT 5 and OPT 6 copy the output on connector 3 or 7. OPT 7 and OPT 8 copy the output on connector 4 or 8. |
