NEC 46″ V463 HD LCD Monitor
LED Edge-Lit Display - OPS / Expansion Slot

Rent It

Choose this option to add gear to a rental quote.
ADD TO QUOTE
Share On Facebook
Share On Twitter
Share On Pinterest
Share On Linkedin
Share On Reddit
Share Via Email
46” High-Performance LED-Backlit Commercial-Grade Display

NEC’s 46” V463 high-performance large-screen display utilizes LED backlighting to deliver both environmental and functional benefits for digital signage. The V463’s commercial-grade panel is capable of displaying brilliant imagery and capturing the audience’s attention.
  • LED backlighting technology reduces power consumption and allows for a slimmer cabinet depth
  • Built-in expansion slot supports the Open Pluggable Specification (OPS)
  • Full 1080p high-definition resolution provides stunning detail
  • Commercial-grade LCD panel and components enable extended run time
  • Expanded connectivity with digital loop-through
  • TileMatrix™ allows you to create video walls up to 10 x 10
Product Specifications
Display
Panel Technology A-MVA
Viewable Image Size 46″
Native Resolution 1920 x 1080
Pixel Pitch 0.53mm
Backlight Type LED Edge-lit
Pixels Per Inch 47@ native resolution
Brightness (typical) 350cd/m2
Brightness (maximum) 500cd/m2
Contrast Ratio (typical) 4000:1
Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Refresh Rate 60Hz
Aspect Ratio 16:9
Active Screen Area 40.1x 22.5in. /1018.1 x 572.7mm
Orientation Landscape/Portrait
Displayable Colors More than 16.7 million
Synchronization Range
Horizontal (Analog/Digital) 31.5-91.1 kHz
Vertical 50-85 Hz
Input Signal
Video Analog RGB 0.7 Vp-p/75 Ohms
Sync Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)
Connectivity
PC Signal Compatibility Yes
Macintosh Compatibility Yes
Input Terminals
Digital DisplayPort, HDMI, DVI-D
Analog VGA 15-pin D-sub (shared S-Video, Video, Component), BNC Composite
Audio Stereo Mini-Jack, HDMI Audio, DisplayPort Audio
External Control RS-232C, Ethernet (RJ45), IR Remote, DDC/CI
Output Terminals
Audio Stereo Mini-Jack, External Speaker Jack (2)
Digital DVI-D
External Control RS-232C
Power Consumption (typical)
On 76W
ECO Mode Standby <2W
Physical Specifications
Bezel Width (Left/Right, Top/Bottom) 0.7 in./0.7 in., 0.7 in./0.7 in. ; 18.3mm/18.3mm, 18.3mm/18.3mm
Dimensions (WxHxD)
Net (with stand) 41.7 x 25.6 x 9.4in. / 1058.2 x 649.8 x 240.0mm
Net (without stand) 41.7 x 24.1 x 2.6in. / 1058.2 x 612.8 x 65.1mm
Weight
Net (with stand) 44.5 lbs. / 20.2 kg
Net (without stand) 41.7 lbs. / 18.9 kg
