Key Facts
- PIXERA four QUAD
- PIXERA Control CORE License
- 16TB NVMe-SSD Storage
- 1GbE Quad Network Card
- 25GbE Dual Network Card
- 12G-SDIÂ Input/Output or 4x 3G-SDI
- 1x HDMI 2.0 Input
- Framelock and Genlock
- Dante Virtual Sound Card
Additional information
Case Dimension (WxDxH) | 445 x 482 x 176mm |
---|---|
Product Weight | 18.5kg |
Rack Dimensions (depth between X and Y) | 550mm and 1250mm |
Server Grade Hardware Components | Yes |
CPU Type | AMD Epyc |
CPU Performance Index | 68 |
CPU # of Cores / # of Threads | 24/48 |
CPU Min/Max Frequency | 2.85/4.0GHz |
RAM | 128GB |
RAM Channels used | 8 |
ECC RAM | Yes |
Power Supply | 100-240VAC, 50-60Hz |
Power Consumption Peak | 900W |
Heat Dissipation Peak | 3071BTU/h |
Heat Dissipation Average with High Load* (Standard Config) | 1535BTU/h |
Operating System Amount of Physical NVMEs | 1 |
Data NVMe Capacity (Net) | 3.84TB (Optional: 8TB, 15TB, 30TB, 60TB) |
Data NVMe Max. Read Rate | 10GB/s (Up to 20GB/s) |
Uncompressed Content Playback | Yes |
Licensed Video Outputs | 1-2 |
Physical Video Outputs | 4 |
Video Output Standard | DP1.4 |
Video Output Resolution (Max.) | 5120x2880 |
EDID Management | Yes |
Genlock | Optional |
Framelock | Optional |
GUI Outputs | Optional |
GUI Output Standard | Optional (4x mDP1.4) |
Max. GUI Output Resolution | Optional (4096x2160) |
USB | 2x USB3 Front, 1x USB-C Front, 2x USB3 Rear, 1x USB-C Rear |
Network | 2x10Gbps (Optional: 4x1Gbps, 2x25Gbps) |
IPMI | 1xIPMI LAN |
Video Inputs (Not all configs possible*) | HDMI 2.0 Optional 3G-SDI Optional 12G-SDI Optional |
Audio Inputs (Not all configs possible*) | Analog Balanced Stereo balanced (quarter-inch TRS jack) SPDIF Optional AES/EBU Optional ADAT Optional Dante virtual soundcard Optional |
Temperature (altitude less than 1000m, no direct sunlight) | 10°C to 30°C |
Temperature De-Rating (altitude more than 1000m) | Reduce max. temperature by 1°C per 300m |
Maximum Altitude | 3000m |
Relative Humidity (nonconsidering) | 20% RH to 80% RH |
Maximum Humidity Gradiation | 10% RH per hour |
Temperature (no direct sunlight) | -30°C to 55°C |
Maximum Temperature Gradation | 20°C per hour |
Relative Humidity (noncondensing) | 5% RH to 95% RH |
Maximum Humidity Gradation | 10% RH per hour |
Operating Noise Idle | 34dB(A) |
Operating Noise Max. | 52dB(A) |
Operating System | Windows 10IoT x64 |
Pixera Software License | PIXERA Director |
Layers | Unlimited |
Playout | Unlimited |
Local Editing | Yes (GUI Output recommended) |
3D Visualization | Yes (GUI Output recommended) |
Network Master/ Manager | Yes |
Rendering (Output, Visu) | Yes (GUI Output recommended) |
PIXERA control | PIXERA control GATE |
