The numbers on site
3-chip class color brightness out of a 1-chip DLP body. Here's what the PT-HTQ20 actually puts on the screen, measured the way your production team measures it.
Rated at 20,000 lm (ANSI) with a 21,000 lm center measurement — full output maintained on both 120V and 240V power, so touring rigs don't lose brightness crossing borders.
Engineered for the rig
Every spec below is the kind that shows up in an RFP, not a brochure — sourced from Panasonic's own PT-HTQ20 documentation.
Rec. 2020 color, 1-chip footprint
Proprietary RGB-plus-phosphor laser design closes in on 3-chip DLP color brightness while keeping the compact, single-chip form factor.
Smoother gradients, less artifacting
An enhanced Gradation Smoother reduces banding in Rec. 709 content, and Panasonic's rainbow-reduction tech tackles the artifact single-chip DLP is known for.
20,000 hours, no filter swaps
A sealed, filterless optical path keeps this projector in service through back-to-back load-ins without a maintenance window baked in.
The show survives a laser bank drop
Multi-Laser Drive Engine failover keeps output running if a laser bank fails mid-event — redundancy where it actually matters.
2K/240 Hz playback
Built for high-motion content, simulation, and fast-cut show graphics that standard 60 Hz projection can't keep up with.
Full brightness, 120–240V
Output doesn't derate when a rig moves between US and international power — one spec sheet for every venue on the tour.
12G/3G/HD-SDI + dual 4K/60p HDMI
Built-in SDI and HDCP 2.3-compatible HDMI inputs handle broadcast and production signal chains without extra converter boxes.
Room to grow
An open Intel® SDM-standard expansion slot accepts the ET-SBFMP10 media processor and future function boards as your workflow evolves.
Built for your stage
Live Events & Rental
Output that holds up under ambient light and truss-mounted, deck-focused rigging.
Staging & Production
Front and rear projection, 360-degree install orientation, fast turnaround load-ins.
Museums & Attractions
Filterless, 20,000-hour operation for exhibits that run open-to-close, every day.
House of Worship
Quiet 42 dB operation and wide lens shift for balconies and off-axis installs.
Event Producers
Network monitoring and PJLink control for multi-projector shows managed from one seat.
Reserve before the general release
Nationwide Video is taking presale orders on the PT-HTQ20 ahead of its October 2026 ship date, with two exclusive discount options available through the window below.
Road-Ready Package
Order the PT-HTQ20 with a frame and road case bundled in — ready to load straight into rotation.
- Frame included
- Road case included
- One presale price, simple and easy.
Choose 1 Free Item
Order the PT-HTQ20 on its own and pick one item to add at no charge.
- Frame, or
- Road case, or
- LES250 Lens
Technical specifications
Pulled directly from Panasonic's PT-HTQ20 documentation for the details an integrator actually needs before quoting a room.
| Projector type | 1-Chip DLP™ RGB laser projector |
| Light source | Laser diodes — Red LD, Green LD, Blue LD |
| Light output | 20,000 lm (ANSI) / 21,000 lm (Center) |
| Light output longevity | 20,000 hrs to 50% (NORMAL) · 24,000 hrs (ECO) |
| Resolution | 4K — 3840 × 2400 dots (Quad Pixel Drive: On) |
| DLP panel | 24.4mm (0.96in) diagonal, 16:10 · 2,304,000 pixels (1920×1200 native) |
| Contrast ratio | 25,000:1 (All white / All black, Dynamic Contrast) |
| Screen size range | 70–1000 in diagonal (depending on attached lens) |
| Lens shift | Vertical ±55% max · Horizontal ±20% max (lens dependent) |
| Installation | Ceiling/floor, front/rear, free 360-degree orientation |
| Video inputs | 2× HDMI (HDCP 2.3, 4K/60p) · 12G/3G/HD-SDI |
| Control I/O | RS-232C serial · RJ-45 LAN (PJLink Class 2, Art-Net) · Multi Projector Sync in/out |
| Expansion | 1× Intel® SDM-standard slot for function boards |
| Power supply | AC 100–120V or AC 200–240V, 50/60Hz |
| Max power draw | 1,430W (100–120V) · 1,450W (200–240V) |
| Operation noise | 42 dB (NORMAL/ECO) |
| Dimensions (W×H×D) | Approx. 23 7/32" × 8 21/32" × 23 5/8" (excl. feet, lens) |
| Weight | Approx. 85.3 lbs |
| Operating range | 32–113°F · 10–80% humidity, no condensation |
| Control protocols | Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net, AMX® DD, Extron® XTP, PJLink™ |
Reserve your PT-HTQ20
Tell us how you plan to run it and a Nationwide Video specialist will follow up with presale pricing, lead time, and your Option 1 / Option 2 details.
Prefer to talk it through first?
Call 800.935.2323 or email sales@nationwidevideo.com
